PTFE VALE STEM PACKING

Description:

TOP SEALING PTFE VALE STEM PACKING is made with uncentered PTFE. PTFE is resistant to all chemical products and solvents with the exception of alkaline materials. It has good resistance to elevated pressures and has a high thermal stability. Expanded PTFE tape is odourless and tasteless making it suitable for food applications.

Detail Image

Product Details

Description\ Item		PTFE (Polytetrafluoroethylene)
Description\ Item		English	Metric
Tensile strength		1,500-3,000psi	103-206bar
Flexural modulus		72,000psi	4964bar
Izod Impact	Notched	3.5ft-lbs/in	7KJ/m2
Heat Deflection Temperature	at 66 psi	250℉	120℃
Continuous Temperature	Maximum	500℉	260℃
Water Absorption	Immersion 24 hours	<0.01%
Coefficient of Linear Thermal Expansion		8.9in/in/ºFx10-5
Coefficient of Friction	Dynamic	0.1

More Styles

Application Data

Advantages

Video

Comparison Vision

Property	Description	Value
Property	Description	English	Metric
Material	100% Expanded PTFE	-	-
Color	White	-	-
Temperature Limits	Continuous	-450℉ to 525 ℉	-268℃ to 273 ℃
Temperature Limits	Intermittent	-450℉ to 600℉	-268℃ to 315℃
Tensile Strength		1015Psi	7Mpa
Elongation at Break	-	140%
pH range	-	0-14
Compressibility	-	52%
Salability	-	0.03ml/hr
Size	Thickness	0.08-0.4in	2-10mm
	Width	0.1-1.6in	3-40mm
	Length	195in, 390in, 590in, 787in	5m, 10m, 15m, 20m

Simply you can wholesale PTFE VALE STEM PACKING direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and PTFE VALE STEM PACKING suppliers known by the world since 2000.
