Texturized Fiberglass Yarn

Description:

TOP SEALING Texturized Fiberglass Yarn 3600C is manufactured by E-glass fiber filament yarn or C-glass fiber filament yarn. It is widely used in the production of fiberglass fabrics as well as electrical wrapping materials, engineering materials, textured yarn, woven electronic grade fabric and so on. The individual requirements of any fabric could be satisfied by adjusting filament diameter, tex number, yarn twists and number of filled yarn as well.

Texturized Fiberglass Yarn

Detail Image

Product Details

Description Item E-Glass C-Glass
Chemical Composition SiO2   52-56% 64-68%
CaO 16-25% 11-15%
Al2O3 12-16% 3-5%
MgO 0-5% 4-6%
B2O3 5-10% 0-6%
Chemical Resistance-14mm fiber; % weight loss after 1 hr boil in H2O 1.7 0.13
1.04 N NH2SO4 48.2 0.1
0.1 N  NaOH 9.7 2.28
Temperature Softening Point 840℃/1545℉ 748℃/1380℉
Coefficient of Thermal Expansion-in/in/ °F x 10-7 2℃/29℉ 5℃/40℉
Specific Gravity (bare fiber) 2.52-2.61 2.49
Pristine Tensile Strength, psi 500,000 400,000
Dielectric Constant, 72 °F, 106 Hz  6.1-6.7 6.24



More Styles

Application Data
Advantages
Video
Comparison Vision
Description\Style No. 3600ETK 3600ETC 3600CTK 3600CTC
Glass Type E-Glass C-Glass
Colour White
Processing type K-Style C-Style K-Style C-Style
Fiber diameter 6,9,11Micron 11Micron
Yarn Diameter 400Tex+/-30
600Tex+/-40
800Tex+/-60
1000Tex+/-80
1200Tex+/-100
2400Tex+/-200
5000Tex+/-500
Water Content 0.10% 0.20%
LOI ≤15%
Thermal Conductivity <0.035k/m.hr.Co
Tensile Strength ≥ 52
Breaking Strength 60-1000

Simply you can wholesale Texturized Fiberglass Yarn direct from manufacturers.
