Inconel Wire Jacked Mesh Graphite Gland Packing

Description:

TOP SEALING Inconel Wire Jacked Mesh Graphite Gland Packing STYLE 5800MESH is Super-high Temperature & Pressure Valve Packing, is braided from low-sulphur expanded graphite yarn with corrosion inhibitor. reinforced with inconel wire Each yarn is round braided with inconel mesh again The packing is diagonal braided to form a dense but pliable packing, fu rther enhanced with blocking agents.Easy installation and extrusion resistance in single-spool packing Special for high pressure High
temperature steam service.

Detail Image

Product Details

Regular：3m, 8m, 1kg, 1 pound, 2.5kg, 2.5 pound, 5kg, 5 pound,10kg, 10 pound.

Other packages are available on request

Normal Dimension：

Size：3、4、5、6、1/4"、8、3/8"、10、7/16"、12、1/2"、14、16、18、19、20、22、25、30、35、40、45、50

More Styles

Application Data

Advantages

Video

Comparison Vision

Pressure: bar	In steam 450bar
PH Range	0-14
Temp.℃	-240 to +3316 in non-oxid. atm; -240 to +454 in oxid. atm; -240 to +649 in steam
Density: (g/cm³)	1.35-1.40
Size	1/8"-2"
Size	3mm-50mm

Super-high Temperature & Pressure Valve Packing . The exclusive packing is formable, yet tough Rated in steam service 450bar. maintains integrity in steam up t0 649 C it is a cost effective as well as a confident choiceit is for steam. water. oil. solvents. alkalies. acids. and most chemicals Exceptions are oleum . fuming nitric acid, aqua regia, and fluorine. and high temperature valve and other static applications, as well as some rotary applications such as soot blowers or rod packings.

Simply you can wholesale Inconel Wire Jacked Mesh Graphite Gland Packing direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Inconel Wire Jacked Mesh Graphite Gland Packing suppliers known by the world since 2000.
