CERAMIC FIBER BLANKET

Description:

TOP SEALING CERAMIC FIBER BLANKET Made from bulk fibres produced by the most modern spinning process, giving exceptional length and uniform distribution which are ideal for manufacturing blanket of controlled density, high tensile strength and resiliency. They have superior acoustic as well as thermal insulation characteristics. It is ideal for furnace, boiler duct and stack lining due to its low-thermal conductivity and low-heat storage allowing shorter cycle times and quicker access for maintenance.

Detail Image

Product Details

Description\Grade		COM	STD	HP	HA	HZ
TENGLONG style		4220C	4220ST	4220HP	4220HA	4220HZ
Classification Temperature	English	1922℉	2300℉	2300℉	2480℉	2606℉
Classification Temperature	Metric	1050℃	1260℃	1260℃	1360℃	1430℃
Operating Temperature	English	<1832℉	<1922℉	<2010℉	<2192℉	<2462℉
Operating Temperature	Metric	<1000℃	<1050℃	<1100℃	<1200℃	<1350℃
Color		White	Spotlessly White	Spotlessly White	Spotlessly White	Spotlessly White
Density	English	6 lb/ft³-8 lb/ft³	6 lb/ft³-8 lb/ft³	6 lb/ft³-8 lb/ft³	8 lb/ft³-10 lb/ft³	8 lb/ft³-10 lb/ft³
Density	Metric	96-128kg/m³	96-128kg/m³	96-128kg/m³	128-160kg/m³	128-160kg/m³
Specification	English	283.46×24.02×0.98inch; 141.73×24.02×1.97inch
Specification	Metric	7200×610×25mm; 3600×610×50mm Other Size can be made on request.

More Styles

Application Data

Advantages

Video

Comparison Vision

Description\Grade		COM	STD	HP	HA	HZ
TENGLONG style		4220C	4220ST	4220HP	4220HA	4220HZ
Classification Temperature	English	1922℉	2300℉	2300℉	2480℉	2606℉
Classification Temperature	Metric	1050℃	1260℃	1260℃	1360℃	1430℃
Fiber Diameter		3.5um	3.5um	3.5um	3.5um	3.5um
Tensile Strength (MPa)		0.08-0.12	0.08-0.12	0.08-0.12	0.08-0.12	0.08-0.12
Chemical Composition	Al2O3	44%	46%	47-49%	52-55%	39-40%
	Al2O3+SiO2	96%	97%	99%	99%	-
	Al2O3+SiO2+ ZrO2	-	-	-	-	99%
	ZrO2	-	-	-	-	15-17%
	Fe2O3	<1.2%	<1.0%	0.20%	0.20%	0.20%
	Na2O+K2O	≦0.5%	≦0.5%	0.20%	0.20%	0.20%

Mainly serve as the ceramic fiber lining for industrial furnaces, heating equipment and high- temperature pipelines, such as Metallurgy Industry: heating furnaces, heat treatment furnaces and ladle insulated cover Mechanism industry: thermal insulation material for electric power boilers, gas turbine engine and nuclear power plant "Petrochemical industry: the lining of high-temperature reaction equipment and heating equipment in chemical fields, like converting furnaces, constant/reduced pressure furnaces, cracking furnaces, flue lining." Ceramics and electro ceramics: roller hearth furnaces, tunnel furnaces , shuttle furnaces and other kinds of furnaces

Simply you can wholesale CERAMIC FIBER BLANKET direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and CERAMIC FIBER BLANKET suppliers known by the world since 2000.
